Product Description

 General Description

The device is remote LED uses a state-of-the-art designs.This LED is designed to be used with detectors. one 8mm LED provide local 360degree visible alarm indication. They flash with the same as detector that be connected.

Features and Benefits

1.Compatible with all the conventional fire alarm control panel

2.8mm big size LED

3.Outside two holes provide 83mm(USA)

4.Inner two holes provide 59mm(Europe)

5.Wiring Terminals provided on the PCB board

Technical specifications

System voltage: 3VDC

Alarm current:20mA@24VDC

Operating temperature range: -10C to 50C

Operating humidity range:10% to 93% relative humidity,Noncondensing

Latching Alarm: Reset by momentary power interruption

Size:102x86x32mm

Weight: 50g





Payment Terms︰ TT/WU

Product Image
